Product details
| PoE Ports | 16 PoE Ports |
| Network Port | 16 x 10/100 Mbps Base-TX RJ45 ports (Data/Power) 2 x 10/100/1000 Mbps Base-T RJ45 ports (Data) 1 x 10/100/1000 Mbps Base-X SFP port (Combo) |
| LED light | 16 x Link/Act LEDs 1 x G1 LED 1 x G2/SFP2 LED 1 x PoE-MAX LED 1 x Power LED |
| PoE Standard | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at |
| Switch Capacity | 7.2 Gbps |
| Input Voltage | 100-240V/50-60Hz |
| PoE Power Supply | Ports 1-16 support standard IEEE802.3af/at 30W output per PoE port 130W output of the total PoE Power |
| Forwarding Rates | 5.36 Mpps |
| Power Consumption | 150W output the whole device |
| MAC Address List | 4K |
| Four Modes | Standard: Default mode of the switch. In this mode, it works as an unmanaged switch; all ports can communicate each other separately. Priority: In this mode, port G1 and G2/SFP2 serve as uplink ports, ports 1 – 8 serve as high priority port. All ports can communicate each other separately. Extend: In this mode, data rate of ports 9 – 16 reduces to 10 Mbps, the maximum transmission distance can be 250 meters, and all ports can communicate each other. VLAN: In this mode, ports 1 – 16 of the switch can communicate port G1, G2/SFP2 separately, but cannot communicate each other. You can enable this mode to reduce broadcast storm and isolate DHCP broadcast. |
| Lightning Protection | ≥6KV |
| Operating Temperature | 0°C ~ 45°C (32°F ~ 113°F) |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) |
| Storage Humidity | 5% ~ 90% non-condensing |
| Dimension | 294mm×178.8mm×44mm |
